Description

Product Description

Best cnc router in india for woodworking specifically designed for cutting, routing, and engraving various materials, primarily wood, functions as a computer-controlled machine. In the woodworking industry, woodworkers widely utilize Woodworking CNC Machine for various tasks such as cutting, shaping, and carving wood. Similarly, they can create intricate designs, patterns, and contours that would be difficult or impossible to achieve manually. contact us to know about Best cnc router in india for woodworking Price.

CNC Router AC Servo 750W 1325specifications:

• • • Working Area: 1300×2500×280 mm,
    • Heavy Weld Tube Structure,
    • Cast Side Support with 3 Tones Loading Capacity,
    • Spindle Power:  2.2 kw / 3.5 kw / 4.5 kw / 6.0 kw / 7.5 kw,
    • Spindle Type: Air Cooled / Water Cooled / ATC Spindle, 18,000 / 24,000 rpm,
    • Spindle Brand: HQD / HSD Mechatronics / Hiteco Italy,
    • INVT Taiwan / Innovance / ABB / Siemens VFD,
    • Richauto A11 Plus / Weihong NK105 / Weihong NC-Studio CNC Control System,
    • Drive & Motor Brand: Leadshine / Yako / Moons / Delta / Yaskawa / Moons
    •  AC Servo Drive and AC Servo Motor 750W,
    • Rapid Speed:  25,000 mm / min, Working Speed: 14,000 mm/ min,
    • Taiwan Hiwin / THK 20 mm High Load Linear Rail and Linear Bearing,
    • Taiwan TBI 25 mm z axis ball screw,
    • Cable: German Lapp / Igus cables,
    • 1.25 m Helical Harden Rack and Pinion.
    • Transmission: Timing Belt Gearbox / Planetary Reducer Gearbox,
    • Gearbox Brand: Japan Shimpo / Liming / Apex,
    • Standard T-Slot Aluminium Profile 1.5 mm / 4.0 mm,
    • Support Program: G Codes and M Codes,
    • Software: Artcam, Aspire, DeskProto,
    •  Lubrication: Manual / Automatic,
    • Voltage 220 v, Single Phase 50hz,
    • Standard tools and accessories include Allen key Toolbox, Ball Nose Tools 6 no’s, Spindle Spanner Set, 2 Collet, Collet Nut, Heavy Door Clamp 10 pcs, 2 Sensors,
    • 12,000+ Designs (800 GB) include Single Doors, Double Door, Sofa, Pooja Door, Jali Cutting, ACP Cladding, Bell Cutting, Corner Design,
    • Gross Weight 1500 kgs,
    • Total Power 15.0 Hp,
    • Overall dimension: 3200 x 2300 x 2300 mm.

  • ⚙️ Woodstar AC Servo 750W CNC Router – High-Speed, High-Precision CNC Solution

    Looking to upgrade your workshop with unmatched precision and speed? The Woodstar AC Servo 750W CNC Router offers cutting-edge performance, advanced AC servo motor control, and durable build quality — perfect for professionals in woodworking, signage, furniture, and interior design industries.

    ---

    ✅ What is a AC Servo 750W CNC Router?

    A AC Servo CNC Router is a high-performance machine powered by AC servo motors 750W, known for delivering faster speeds, smoother motion, and superior accuracy compared to Servo-based systems. The Woodstar AC Servo 750w CNC Router combines this advanced motion control with a rugged frame and intelligent software to handle demanding cutting, carving, and engraving jobs effortlessly.

    ---

    🔍 Key Features of the Woodstar AC Servo 750W CNC Router:

    • Precision AC Servo Motors (Yako/Leadshine/Delta/Yaskawa/Moons)
      Ensures fast acceleration, smoother motion, and accurate positioning with closed-loop feedback.

    • Heavy-Duty Welded Frame
      Industrial-grade steel frame minimizes vibrations for long-lasting performance and flawless output.

    • High-Speed Air/Water Cooled Spindle (up to 6kW)
      Cuts through wood, MDF, acrylic, ACP, and even aluminum with ease.

    • Smart Controller
      Comes with a user-friendly DSP Controller (RichAuto A11, NcStudio, or Syntec) for standalone or PC-based operation.

    • Ball Screw/Helical Rack Drive System
      Guarantees smooth motion and reduced backlash on all axes.

    • Vacuum Table with T-Slot
      Dual table system for firm workpiece holding, increasing productivity and precision.

    • Compatible Software
      Works seamlessly with ArtCAM, Aspire, Fusion 360, and other industry-standard CAM software.

    ---

    🧰 Applications of Woodstar AC Servo 750W CNC Routers:

    • Wooden Door & Cabinet Manufacturing

    • Custom Furniture Production

    • 3D Carving & Pattern Making

    • Signboard & Engraving Jobs

    • Aluminum and Acrylic Cutting

    • Interior Panel & Decorative Work

    ---

    🚀 Why Choose Woodstar AC Servo CNC Routers?

    • 🔧 High-Speed Machining with Superior Accuracy

    • 💼 Built for Industrial Use and Heavy Loads

    • 🧠 Intelligent Software Integration

    • 🔋 Energy-Efficient and Low Maintenance

    • 🛠️ Custom Sizes Available (e.g., 1325, 1530, 2030, 2040)

    ---



  • ✅ Advantages:

    • Cost-effective automation for woodworking and signage industries.

    • High accuracy and repeatability suitable for both simple cuts and complex 3D carvings.

    • Easy to operate and maintain with widely available components.

    • Ideal for cabinet making, furniture design, signage, prototyping, and custom woodwork.

  • 📦 Woodstar CNC Router for Sale – Custom-Built to Your Needs

    Whether you’re a startup workshop or an established production unit, the Woodstar AC Servo CNC Router delivers the precision, speed, and reliability your business demands. Available in custom table sizes, tool change options, and multiple spindle setups.

• Overall, best CNC router machine for wood have revolutionized woodworking by offering efficiency, precision, and the ability to create intricate designs that were previously difficult to achieve manually. Moreover, Wood CNC Machine can work with a wide range of wood types, densities, and sizes. Furthermore, they are used in furniture manufacturing, cabinetry, sign-making, and decorative woodworking.

  Fill Enquiry Form for Woodstar CNC Router AC Servo 750W 1325 Price and to know more about CNC Router Machines.
