Jaw Flexible Coupling

Original price was: ₹2,800.Current price is: ₹2,500.

  • Jaw Flexible Coupling

6 in stock


 Product Package:

  • 3pcs – Jaw Flexible Coupling

    Note: Length is 66mm, diameter is 40mm, the inside diameter is from 8mm to 22mm.

Product Description

3pcs - Jaw Flexible Coupling 40 mm

  • Material: Hard aluminum alloy LY12
  • Sleeve Material: Polyurethane
  • Rated Torque: 9.5 Nm
  • Max. Torque: 19 Nm
  • Accuracy: 0.02-0.05mm
  • Diameter: 40mm
  • Length: 66mm


  • The overall processing, light weight, small size
  • Can absorb vibration, spring action to compensate radial, angular and axial deviation, zero backlash
  • Clockwise and counterclockwise rotary characteristics are identical
  • The anti-oil, anti-corrosion
  • Made of hard aluminum alloy and stainless steel
  • Set Screw Clamp or fixed coupling can keyway according to customer demand for processing.
  • Integrated design, installation is simple, commonly used in servo motor, stepper motor, encoder, screw driving, machine platform connection
